ACO PowerDrain 99590 4-Bolt Slotted Ductile Iron Grate - S100K System
For personalized assistance or a customized quote, call us directly at (803)-324-3225. Our team can help confirm component compatibility and project quantities.
Product Details: ACO PowerDrain 99590 4-Bolt Slotted Ductile Iron Grate - S100K System
The ACO PowerDrain 99590 is a removable slotted ductile-iron grate for the S100K channel system, whose live card lists 4" as the system width. Its 4-bolt locking, 0.71" x 1.81" avg. opening pattern, and published 36.00 in² intake area support selection by security, accessibility, hydraulic opening, and traffic requirements.
This 19.69" grate weighs 10.80 lbs. The verified current system class is EN 1433 Class F; the live card separately lists FAA airside guidance: 200,000 lb proof load. The realized system rating also depends on the compatible channel, concrete, installation detail, and assembly.
Quick Look
- ACO Part Number: 99590
- Compatible System: PowerDrain S100K (4" listed system width)
- Listed Length: 19.69"; System Compatibility Width: 4"
- Material: ductile iron; Design: Slotted
- Locking: 4-bolt locking
- Slot Size: 0.71" x 1.81" avg.
- Intake Area: 36.00 in²
- Published Weight: 10.80 lbs
- Verified System Class: EN 1433 Class F
- Current Live-Card Load: FAA airside guidance: 200,000 lb proof load
- Current Live-Card Site-Need Labels: Bicycle Safe, Anti-Slip
Additional Resources
Official ACO Specification Sheet| Brand | ACO |
|---|---|
| Part Number | 99590 |
| Length | 19.69" |
