ACO PowerDrain 02449 PowerLok Slotted Ductile Iron Grate - S200K System
For personalized assistance or a customized quote, call us directly at (803)-324-3225. Our team can help confirm component compatibility and project quantities.
Product Details: ACO PowerDrain 02449 PowerLok Slotted Ductile Iron Grate - S200K System
The ACO PowerDrain 02449 is a removable slotted ductile-iron grate for the S200K channel system, whose live card lists 8" as the system width. Its PowerLok boltless locking, 0.71" x 3.62" avg. opening pattern, and published 70.10 in² intake area support selection by security, accessibility, hydraulic opening, and traffic requirements.
This 19.69" grate weighs 30.80 lbs. The verified current system class is EN 1433 Class F; the live card separately lists FAA airside guidance: 200,000 lb proof load. The realized system rating also depends on the compatible channel, concrete, installation detail, and assembly.
Quick Look
- ACO Part Number: 02449
- Compatible System: PowerDrain S200K (8" listed system width)
- Listed Length: 19.69"; System Compatibility Width: 8"
- Material: ductile iron; Design: Slotted
- Locking: PowerLok boltless locking
- Slot Size: 0.71" x 3.62" avg.
- Intake Area: 70.10 in²
- Published Weight: 30.80 lbs
- Verified System Class: EN 1433 Class F
- Current Live-Card Load: FAA airside guidance: 200,000 lb proof load
- Current Live-Card Site-Need Labels: Bicycle Safe
Additional Resources
Official ACO Specification Sheet| Brand | ACO |
|---|---|
| Part Number | 02449 |
| Length | 19.69" |
