ACO Drain Shortened Tee Fabrication - Cut & Bonded or Male/Female Details Added (K100/KS100)

Product Details: ACO Drain Shortened Tee Fabrication - Cut & Bonded or Male/Female Details Added (K100/KS100)

Standard modular parts cover most ACO KlassikDrain K100/KS100 trench runs — but not all of them. For layouts that call for a shortened section, a change of direction, a mitered 90° corner, a tee intersection, or an outlet where no factory knockout exists, ACO offers a made-to-order fabrication service for its polymer concrete channel systems. Each product here is that shop work itself: a fabrication ordered together with the channel sections it is performed on — cut, bonded, core-drilled, or remodeled at the factory to match your project drawings.

On most fabrications, the male-to-female connection details are remodeled so the finished piece drops into a standard channel run; depending on the service, parts ship assembled or as un-assembled sections for alignment on site. Because every fabrication is configured to a specific layout, these services are quoted per project — send us your drawings and our team will handle the rest.

This listing covers ACO's shortened-tee fabrication: a tee intersection in which one branch is shorter than a full 1 m section, finished with a closing cap attached. Depending on the configuration, the channel sections in your order are cut and bonded at the factory, or male/female connection details are added so the sections align in a standard run. The service covers the ACO Drain K100, KS100, and NW100 channel lines. Per ACO, parts are only shipped assembled where one channel is less than 19.69" (500 mm); otherwise the sections ship for assembly on site.

Quick Look

• Made-to-order fabrication service performed by ACO — shop labor applied to the channel sections in your order, not a stocked, off-the-shelf part
• Ordered alongside the KlassikDrain channel material it is applied to; channel sections, grates, and accessories are quoted separately
• Performed on high-strength polymer concrete channel bodies from ACO's 4" (100 mm) KlassikDrain K100/KS100 line — each listing states its exact range of compatible ACO channel systems
• Fabricated sections are designed to integrate with the standard K100/KS100 male-to-female interconnecting end profile
• Configuration is confirmed against your trench run layout at quoting, so the fabrication matches the channels it joins
• Quote-only service: request a quote with your layout and the channel sections involved, and our team will confirm the correct fabrication with ACO
• ACO Part Number: 06632
• Service: shortened tee — a tee intersection with one branch shorter than a full 1 m section, supplied with a closing cap attached
• Fabrication method: channel sections are cut and bonded at the factory, or male/female connection details are added, depending on the configuration
• Compatible ACO Drain channel lines: K100, KS100, and NW100
• Shipping: parts are only shipped assembled where one channel is less than 19.69" (500 mm)

The shortened tee is one of several made-to-order fabrications available for the KlassikDrain line. To pair it with the channel sections, grates, and accessories it is performed on, start with the system overview:
