ACO Heel-Resistant Brickslot 100 Type 483 Galvanized Steel Access Unit - 0.5 Meter

Product Details: ACO Heel-Resistant Brickslot 100 Type 483 Galvanized Steel Access Unit - 0.5 Meter

The ACO Brickslot 100 series replaces a conventional grate with a discreet slot-top for the KlassikDrain K100 and KS100 trench drain system. Fabricated from 11 gauge steel, each unit fits directly into the channel's grate recess and presents only a narrow drainage slot at the finished surface. Brick pavers fit directly against the slot — the units are designed for 80 mm pavers including 1/8" (3 mm) of bedding — so stormwater is captured along an almost seamless line in plazas, walkways, and other commercial spaces where unobtrusive drainage is essential.

Rated to EN 1433 Load Class C, Brickslot 100 installs without bolts or locking hardware and pairs with K100/KS100 channels as well as Series 900 catch basins. The range spans galvanized and stainless steel construction, standard and heel-resistant slot geometries, 1 meter and 0.5 meter lengths, and half-meter access units that keep the covered system serviceable.

The Heel-Resistant Type 483 (ACO part number 138052) is the galvanized steel access unit of that heel-resistant range: a 19.69" (500 mm / 0.5 meter) frame in 11 gauge galvanized steel with a separate removable insert that provides maintenance access to the channel, trash bucket, or outlet pipes beneath the covered surface. Its heel-resistant slot geometry — offset double 5/16" (8 mm) slot openings flaring to a 7/8" (22 mm) throat — complies with ADA 2010 Sec 302.3 and ASME A112.6.3 Sec 7.12, and the unit carries ADA Compliant, Bicycle Safe, Heel-Resistant, and LEED credentials. Like every Brickslot 100 unit, the 11.0 lb Type 483 rests in the channel grate seating with no DrainLok or QuickLok hardware — anti-shunt lugs prevent lateral movement, and the weight of the covering material secures the unit — while the assembly stands 3.27" (83 mm) tall and adds 4.06" (103 mm) above the overall channel depth.

Quick Look

• ACO Part Number: 138052 (Type 483 — Heel-Resistant Brickslot 100 Access Unit)
• Material: 11 gauge galvanized steel (the Brickslot 100 range is available in galvanized and stainless steel versions)
• Length: 19.69" (500 mm / 0.5 meter) — all Brickslot access units are half-meter units
• Unit Width: 4.84" (123 mm); Unit Height: 3.27" (83 mm); adds 4.06" (103 mm) above the overall channel depth
• Weight: 11.0 lbs
• Load Class: EN 1433 Load Class C (56,202 lbs, 774-1,160 PSI)
• Heel-resistant slot geometry: offset double 5/16" (8 mm) slot openings flaring to a 7/8" (22 mm) throat
• ADA 2010 Sec 302.3 and ASME A112.6.3 Sec 7.12 compliant
• Access unit: frame with a separate removable insert providing maintenance access to the channel, trash bucket, or outlet pipes
• Fits directly into the K100/KS100 channel grate recess, replacing a standard grate
• Designed for 80 mm brick pavers including 1/8" (3 mm) bedding — pavers fit directly against the slot
• No DrainLok or QuickLok hardware — the unit rests in the channel grate seating, anti-shunt lugs prevent lateral movement, and the weight of the covering material secures it
• For use with K100/KS100 channels and Series 900 catch basins; also usable with MembraneDrain and SlabDrain (H100-10 / H100-8 / H100K-8) channels
• End caps and accessories available from the K100 range
• ADA Compliant, Bicycle Safe, Heel-Resistant, and LEED

Shop the full ACO KlassikDrain K100 Trench Drain system
