ACO K3 Universal Inlet / Outlet End Cap

Product Details: ACO K3 Universal Inlet / Outlet End Cap

ACO part 96826 is a purpose-built component for the KlassikDrain K300 system. It closes a K300/KS300 channel end or provides the line's formed end connection for 6-inch, 8-inch, or 10-inch Schedule 40 pipe. Using the identified factory part preserves the fit between the channel, grate-locking hardware, or catch-basin assembly instead of substituting a generic field component.

This listing is for the ACO K3 Universal Inlet / Outlet End Cap. Confirm the host model and its edge-rail or grate-locking configuration when requesting a quote, especially for replacement parts in an existing installation.

Quick Look

• ACO Part Number: 96826
• Compatibility: K300 and KS300 channels
• Function: Closes a K300/KS300 channel end or provides the line's formed end connection for 6-inch, 8-inch, or 10-inch Schedule 40 pipe
• Published Weight: 2.5 lbs
• Genuine ACO service component; match the part number and catch-basin/channel generation before ordering
• Quote-only listing: Drainage Connect will confirm current availability and the surrounding bill of materials with ACO
• Maximum cap depth 15.71 in (399 mm)
• Bell end fits 6-in, 8-in, or 10-in Schedule 40 pipe

Shop the complete ACO K300 trench drain line
