ACO KlassikDrain 138129 Type 678Q Longitudinal Ductile Iron Grate
For personalized assistance or a customized quote, be sure to call us directly at (803)-324-3225. Our team of experts is on standby to assist you with any questions you may have about our products.
Product Details: ACO KlassikDrain 138129 Type 678Q Longitudinal Ductile Iron Grate
The ACO 678Q grate is engineered for the K200/KS200 trench drain platform. Its Ductile iron construction and QuickLok access arrangement let a designer match surface appearance, opening pattern, accessibility needs, and traffic loading while preserving removable maintenance access.
ACO part 138129 is the Type 678Q Longitudinal Ductile Iron. The published configuration is 19.69" long, weighs 26.00 lbs, and is rated EN 1433 Load Class E - 134,885 lbs, 1,856–2,785 PSI. Select the grate by its own load class and site-need icons; the channel alone does not establish the installed system rating.
Quick Look
- ACO Part Number: 138129; Type: 678Q
- Designed for the ACO KlassikDrain K200/KS200 8" (200 mm) channel system
- Published Length: 19.69"
- Published Weight: 26.00 lbs
- Material / Finish: Ductile iron
- Load Rating: EN 1433 Load Class E - 134,885 lbs, 1,856–2,785 PSI
- Retention / Access: QuickLok
- Opening Size: 1.41" x 0.31" avg.
- Published Intake Area: 51.60 in²
- ADA Compliant
- Bicycle Safe
- Heel Resistant
- Heel Safe
- Anti-Slip
- LEED Certified
Shop the complete ACO K200 trench drain line
Additional Resources
ACO Specification Sheet| Brand | ACO |
|---|---|
| Part Number | 138129 |
| Length | 19.69" |
| Width | 8" |
