ACO KlassikDrain K1-408-6 6 Inch Oval Outlet End Cap - K100 Galvanized Rail

Product Details: ACO KlassikDrain K1-408-6 6 Inch Oval Outlet End Cap - K100 Galvanized Rail

End caps finish and configure the ends of an ACO KlassikDrain K100 or KS100 trench drain run. The KlassikDrain K100/KS100 line is a modular polymer concrete trench drain with a 4" (100 mm) internal clear width, manufactured to EN 1433 standards for commercial and industrial stormwater applications. Inlet end caps let a pipe feed water into the head of the trench, outlet end caps discharge the collected flow into Schedule 40 pipework, and the universal cap serves as a closing, inlet, or outlet cap; each cap is matched to the invert depth of the terminal channel section.

The range covers both edge-rail finishes: the 6" oval inlet and outlet caps are cast in polymer concrete with a matching galvanized (K100) or Grade 304 stainless steel (KS100) edge rail detail, with separate part numbers per rail, while the lightweight plastic universal cap shares one part number across both systems and can be cut down for shallower channels.

The K1-408-6 (ACO part number 96836) is the 6" oval outlet cap for K100 galvanized edge rail channel runs at the 11.81" (300 mm) invert band - the #40 depth, matching sloped channel K1-40 and neutral channels K1-040 and K1-0403. Installed at the discharge end of the run, its plain end fits a 6" Schedule 40 pipe and carries a rated outlet flow of 264 GPM (0.59 CFS) - the highest end-outlet capacity in the range. Because these caps carry an edge rail detail, the galvanized and Grade 304 stainless steel versions have separate part numbers; this is the galvanized (K100) cap.

Quick Look

• End-of-run component for the ACO KlassikDrain K100/KS100 trench drain system with 4" (100 mm) internal clear width
• Works with both sloped (0.5% built-in slope) and neutral (constant-depth) K100/KS100 channel sections
• Connects to Schedule 40 pipe: 6" on the oval inlet/outlet caps, 4" bell end on the universal cap
• Select the cap to match the invert depth of the terminal channel section: oval caps serve a fixed invert band, while the universal cap fits inverts up to 11.81" (300 mm) and can be cut down
• Available for both K100 galvanized edge rail and KS100 Grade 304 stainless steel edge rail channel runs
• Part of the KlassikDrain K100/KS100 channel system manufactured to EN 1433 standards
• Part Number: 96836 (ACO catalog code K1-408-6)
• Function: outlet end cap - plain end discharges the collected flow into a 6" Schedule 40 pipe
• Rated Outlet Flow: 264 GPM (0.59 CFS) at the 11.81" invert - the highest end-outlet capacity in the range
• Fits the 11.81" (300 mm) invert band: sloped channel K1-40 and neutral channels K1-040 / K1-0403
• Material: polymer concrete with galvanized steel edge rail detail (K100)
• Dimensions: 12.99" (330 mm) high x 5.30" (134 mm) wide with a 1.20" (30 mm) thick flange
• Invert Depth: 11.81" (300 mm)
• Weight: 5.8 lbs
• Load Rating: EN 1433 Load Class E - 134,885 lbs / 2,785 psi as part of the installed system
• Galvanized and stainless steel edge rail caps carry separate part numbers - this is the K100 galvanized version
