ACO KlassikDrain K1 Universal Inlet/Outlet/End Cap (K100/KS100)

Product Details: ACO KlassikDrain K1 Universal Inlet/Outlet/End Cap (K100/KS100)

End caps finish and configure the ends of an ACO KlassikDrain K100 or KS100 trench drain run. The KlassikDrain K100/KS100 line is a modular polymer concrete trench drain with a 4" (100 mm) internal clear width, manufactured to EN 1433 standards for commercial and industrial stormwater applications. Inlet end caps let a pipe feed water into the head of the trench, outlet end caps discharge the collected flow into Schedule 40 pipework, and the universal cap serves as a closing, inlet, or outlet cap; each cap is matched to the invert depth of the terminal channel section.

Part number 96822 is the universal cap of the range: one lightweight plastic cap that closes the end of a run, admits flow as an inlet, or discharges it as an outlet through a bell end sized for 4" Schedule 40 pipe. Because it carries no edge rail, the same part number serves both the K100 galvanized and KS100 Grade 304 stainless steel systems - ACO publishes no separate stainless universal cap. At just 0.4 lbs it is by far the lightest end-cap option in the range, and it fits channel sections up to 11.81" (300 mm) invert depth, with the option to cut it down on site for shallower channels.

Quick Look

• End-of-run component for the ACO KlassikDrain K100/KS100 trench drain system with 4" (100 mm) internal clear width
• Works with both sloped (0.5% built-in slope) and neutral (constant-depth) K100/KS100 channel sections
• Part Number: 96822 - one shared part number for both K100 galvanized and KS100 Grade 304 stainless steel edge rail channel runs
• Serves as a closing cap, inlet cap, or outlet cap - shown on the ACO system layout as the "Universal closing/outlet end cap"
• Bell end fits 4" Schedule 40 pipe
• Fits channels up to 11.81" (300 mm) invert depth and can be cut down for shallower channels
• Material: Plastic
• Dimensions: 12.41" (315 mm) max height x 5.30" (134 mm) width x 1.85" (47 mm) deep; 0.13" (3 mm) thick
• Weight: 0.4 lbs - the lightest end-cap option in the range
• Part of the KlassikDrain K100/KS100 channel system manufactured to EN 1433 standards
• Do not confuse with 96821 (K200 universal cap), 96826 (K300 universal cap), or 96825 (legacy K100S/KS100S cap)
