ACO KlassikDrain K2-621G Series 600 Catch Basin - Galvanized Steel Rail, LLDPE Plastic Base

Product Details: ACO KlassikDrain K2-621G Series 600 Catch Basin - Galvanized Steel Rail, LLDPE Plastic Base

The ACO KlassikDrain K2-621G is a factory catch-basin assembly for the K200/KS200 drainage line. Its polymer-concrete top and LLDPE plastic base combine channel connection points, a removable trash bucket, and multiple pipe-outlet drill-out positions in one serviceable collection point.

ACO part 94620 has an overall depth of 37.64 inches (956 mm), a published volume of 24.9 gallons to the grate seat, and a published assembly weight of 91 lbs. This K200 Series 600 assembly takes 0.5 m K300 grates, not K200 grates; the larger grate seat is 11.89 inches (302 mm) wide. Pipe flow values in the ACO drawing describe the selected outlet, not the hydraulic capacity of the connected trench run.

Quick Look

• Catalog Code: K2-621G; ACO Part Number: 94620
• Overall Dimensions: 22.67" x 13.86" x 37.64" (576 x 352 x 956 mm)
• Nominal Clear Opening: 19.69" x 11.89" (500 x 302 mm)
• Published Volume: 24.9 gallons to the grate seat, without trash bucket
• Published Assembly Weight: 91 lbs
• Construction: polymer-concrete top with LLDPE plastic base
• Edge Frame: galvanized steel, with channel-connection drill-outs
• Includes a removable polypropylene trash bucket
• This K200 Series 600 assembly takes 0.5 m K300 grates, not K200 grates; the larger grate seat is 11.89 inches (302 mm) wide.
• Top section includes exterior cast-in anchoring features and 0.59-inch (15 mm) minimum wall thickness
• System load rating: EN 1433 Class E when fitted with an appropriate Class E grate
• Outlet positions and pipe flow rates vary by drill-out; consult the ACO sheet for the selected connection
