ACO KlassikDrain K3-904G In-Line Catch Basin - Galvanized Steel Rail, LLDPE Plastic Base and Plastic Riser 99902

Product Details: ACO KlassikDrain K3-904G In-Line Catch Basin - Galvanized Steel Rail, LLDPE Plastic Base and Plastic Riser 99902

The ACO KlassikDrain K3-904G is a factory catch-basin assembly for the K300/KS300 drainage line. Its polymer-concrete top and LLDPE plastic base and plastic riser 99902 combine channel connection points, a removable trash bucket, and multiple pipe-outlet drill-out positions in one serviceable collection point.

ACO part 94635 has an overall depth of 49.63 inches (1261 mm), a published volume of 40.2 gallons to the grate seat, and a published assembly weight of 98 lbs. Accepts 0.5 m K300 DrainLok grates, or QuickLok grates with the appropriate removable locking bar. Pipe flow values in the ACO drawing describe the selected outlet, not the hydraulic capacity of the connected trench run.

Quick Look

• Catalog Code: K3-904G; ACO Part Number: 94635
• Overall Dimensions: 22.67" x 13.86" x 49.63" (576 x 352 x 1261 mm)
• Nominal Clear Opening: 19.69" x 11.89" (500 x 302 mm)
• Published Volume: 40.2 gallons to the grate seat, without trash bucket
• Published Assembly Weight: 98 lbs
• Construction: polymer-concrete top with LLDPE plastic base and plastic riser 99902
• Edge Frame: galvanized steel, with channel-connection drill-outs
• Includes a removable polypropylene trash bucket
• Accepts 0.5 m K300 DrainLok grates, or QuickLok grates with the appropriate removable locking bar.
• Top section includes exterior cast-in anchoring features and 0.59-inch (15 mm) minimum wall thickness
• System load rating: EN 1433 Class E when fitted with an appropriate Class E grate
• Outlet positions and pipe flow rates vary by drill-out; consult the ACO sheet for the selected connection
