Product Details: ACO PowerDrain SK3-0303 Constant-Depth Trench Drain Channel - 0.5 Meter
The ACO PowerDrain S300K line is a modular heavy-duty drainage system with a clear opening measuring 12" (300 mm). Its polymer-concrete channel body, integral ductile-iron edge rail, partial-radius invert, interconnecting ends, and exterior anchoring keys support a coordinated installation. The installed load class depends on the selected grate and installation detail.
The SK3-0303 (ACO part 69049) is a 0.5-meter constant-depth section with an invert depth of 17.72" (450 mm) and published weight of 100 lbs. This constant-depth section extends or fine-tunes a run without adding built-in fall. This section includes 6" and 8" round bottom-outlet knockouts.
Quick Look
- Model: SK3-0303; ACO Part Number: 69049
- Length: 19.69" (500 mm)
- Internal Width: 12" (300 mm); Overall Width: 14.25"
- Invert Depth: 17.72" (450 mm)
- Published Weight: 100 lbs
- Channel Body: high-strength polyester polymer concrete
- Edge Rail: integrally cast ductile iron
- Channel Profile: partial-radius invert with male/female interconnecting ends and exterior anchoring keys
- Outlet Provision: 6" and 8" round bottom-outlet knockouts
- System Loading: grate-dependent, up to EN 1433 Class F; select the grate and installation detail for the application
- Media Note: family/system photography is illustrative and may show a compatible grate; this bare channel SKU does not include a grate, so select it separately
Additional Resources
Official ACO Specification Sheet| Brand | ACO |
|---|---|
| Part Number | 69049 |
| Length | 19.69" |
| Width | 14.25" |
