US Foundry 192 Round Manhole Frame (21" Clear Opening)
Price available on request
SKU
USF-192
Current US Foundry 192 gray iron round manhole frame with a clear opening of 21", 9" frame height, and flange down frame. Quote to confirm fit and availability.
The US Foundry 192 round manhole frame provides a clear opening of 21", a frame flange diameter of 34", and a frame height of 9". Its current manufacturer record identifies gray iron construction and lists H-20 as the highest load rating.
Frame geometry includes an opening diameter of 24-1/2", a cover diameter of 22-3/4", and a seat depth of 1-3/4". The frame type is Flange Down; request a quote through Drainage Connect to confirm the compatible cover, project configuration, and current availability.
- Current catalog number 192
- Clear opening diameter 21"; cover diameter 22-3/4"
- Frame flange diameter 34"; frame opening diameter 24-1/2"
- Frame height 9"; seat depth 1-3/4"
- Gray Iron construction; Flange Down frame type
- Highest load rating H-20
- Bolted provision; gasket provision
Specification note: Specifications are limited to the exact current manufacturer record. Drainage Connect will confirm fit, configuration, and availability when quoting.
| Brand | US Foundry |
|---|---|
| Part Number | 192 |
| Length | 34" |
| Width | 34" |
| Height | 9" |
| Material | Gray Iron |
| Ratings and Standards | Highest load rating: H-20 |
| Type | Round Manhole Frame |
| Size | 21" Clear Opening |
