US Foundry 4644-6264 Rectangular Inlet Frame & Grate (24-1/8" x 44-1/8" Clear Opening)
Price available on request
SKU
USF-4644-6264
Current US Foundry 4644-6264 gray iron rectangular frame-and-grate combination with a clear opening of 24-1/8" x 44-1/8" and a grate measuring 26-1/4" x 46". Quote to confirm fit and availability.
The US Foundry 4644-6264 rectangular inlet frame-and-grate combination provides a clear opening of 24-1/8" x 44-1/8", grate dimensions of 26-1/4" x 46", and a seat depth of 1-1/2". The current manufacturer record identifies gray iron construction but does not publish a load rating; confirm load requirements when quoting.
Current frame geometry includes an opening of 28-1/4" x 48-1/4", a flange of 28-1/4" x 48-1/4", and a frame height of 2-1/4". Request a quote through Drainage Connect to confirm fit, project requirements, and current availability.
- Current catalog number 4644-6264
- Clear opening 24-1/8" x 44-1/8"; grate 26-1/4" x 46"
- Frame opening 28-1/4" x 48-1/4"
- Frame flange 28-1/4" x 48-1/4"; frame height 2-1/4"
- Seat depth 1-1/2"; Gray Iron construction
- Load rating requires project confirmation
Specification note: Specifications are limited to the exact current manufacturer record. Drainage Connect will confirm fit, configuration, and availability when quoting.
| Brand | US Foundry |
|---|---|
| Part Number | 4644-6264 |
| Length | 48-1/4" |
| Width | 28-1/4" |
| Height | 2-1/4" |
| Material | Gray Iron |
| Type | Rectangular Inlet Frame & Grate |
| Size | 24-1/8" x 44-1/8" Clear Opening |
