US Foundry 4661-6339 Rectangular Inlet Frame & Grate (24" x 48" Clear Opening)
Price available on request
SKU
USF-4661-6339
Current US Foundry 4661-6339 gray iron rectangular frame-and-grate combination with a clear opening of 24" x 48" and a grate measuring 26.625" x 51-3/8". Quote to confirm fit and availability.
The US Foundry 4661-6339 rectangular inlet frame-and-grate combination provides a clear opening of 24" x 48", grate dimensions of 26.625" x 51-3/8", and a seat depth of 1". The current manufacturer record identifies gray iron construction but does not publish a load rating; confirm load requirements when quoting.
Current frame geometry includes an opening of 24" x 48", a flange of 31-3/4" x 55-3/4", and a frame height of 2". Request a quote through Drainage Connect to confirm fit, project requirements, and current availability.
- Current catalog number 4661-6339
- Clear opening 24" x 48"; grate 26.625" x 51-3/8"
- Frame opening 24" x 48"
- Frame flange 31-3/4" x 55-3/4"; frame height 2"
- Seat depth 1"; Gray Iron construction
- Load rating requires project confirmation
Specification note: Specifications are limited to the exact current manufacturer record. Drainage Connect will confirm fit, configuration, and availability when quoting.
| Brand | US Foundry |
|---|---|
| Part Number | 4661-6339 |
| Length | 55-3/4" |
| Width | 31-3/4" |
| Height | 2" |
| Material | Gray Iron |
| Type | Rectangular Inlet Frame & Grate |
| Size | 24" x 48" Clear Opening |
