US Foundry 765-5685 Round Inlet Frame & Grate (21-7/8" Clear Opening)
Price available on request
SKU
USF-765-5685
Current US Foundry 765-5685 gray iron round frame-and-grate combination with a clear opening of 21-7/8" and a grate measuring 23-1/4". Quote to confirm fit and availability.
The US Foundry 765-5685 round inlet frame-and-grate combination provides a clear opening of 21-7/8", a grate diameter of 23-1/4", and a seat depth of 1". The current manufacturer record identifies gray iron construction but does not publish a load rating; confirm load requirements when quoting.
Current frame geometry includes a frame opening diameter of 25-3/4", a frame flange diameter of 32-3/8", a frame height of 4-3/8", and a weir perimeter of 6 ft. Request a quote through Drainage Connect to confirm fit, project requirements, and current availability.
- Current catalog number 765-5685
- Clear opening diameter 21-7/8"; grate diameter 23-1/4"
- Frame opening diameter 25-3/4"
- Frame flange diameter 32-3/8"
- Frame height 4-3/8"; seat depth 1"; Gray Iron construction
- Load rating requires project confirmation
- Weir perimeter 6 ft
Specification note: Specifications are limited to the exact current manufacturer record. Drainage Connect will confirm fit, configuration, and availability when quoting.
| Brand | US Foundry |
|---|---|
| Part Number | 765-5685 |
| Length | 32-3/8" |
| Width | 32-3/8" |
| Height | 4-3/8" |
| Material | Gray Iron |
| Type | Round Inlet Frame & Grate |
| Size | 21-7/8" Clear Opening |
