NDS Spee-D Channel Grate, Decorative Wave Cast Iron

Be the first to review this product

$102.62

In stock

SKU

253CI

Dimensions:Length: 24" x Width: 4.42"

For personalized assistance or a customized quote, Call us directly at (803)-324-3225. Our team of experts is on standby to assist you with any questions you may have about our products.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Product Details: NDS Spee-D Channel Grate, Decorative Wave Cast Iron

The NDS Spee-D Channel Grate, Decorative Wave Cast Iron is part of the NDS Spee-D drainage system. As a proven alternative to traditional concrete drains, NDS grates feature UV inhibitors that prevent fading and cracking from the sun. Channel drains have a unique patented flying buttress design that provides load-bearing support from both sides as well as underneath. Spee-D Channel Drains are ideal for driveways, large decks, and commercial areas. Adequate in everything from patios to light vehicular traffic areas. These chemical-resistant and rustproof grates are maintenance-free, lightweight, and easy to install.

Quick Look

Material: Raw Cast Iron Grate
Open Surface Area: 17.89 Sq. Inch per Ft.
UV Inhibitors
ADA Compliant
Heel-Proof
Dimensions: 24" LENGTH x 4-1/8" WIDTH x 3/4" Height
Install with Four FH #8 x 1 in. screws (Sold Separately)
Fits: NDS Spee-D Channel Drains #400 (4-Foot Section), #400-10 (10-Foot Section)
Will Accommodate 47.60 Gallons per minute with 1/2"of head
Load Recommendation: Class B (61-175 PSI / 28,100 lbs per foot)
